Designed, built and tested to create a strong and visible presence in the work zone!

Includes:
One (1) Roll Up Sign - Includes 4-riveted polycarbonate pockets + orange ribs + velcro strap. Ships in its own package.

Compliance

Section 2C.36 Advance Traffic Control Signs

Standard

The Advance Traffic Control symbol signs (see Figure 2C-6) include the Stop Ahead (W3-1), Yield Ahead (W3-2), and Signal Ahead (W3-3) signs. These signs shall be installed on an approach to a primary traffic control device that is not visible for a sufficient distance to permit the road user to respond to the device. The visibility criteria for a traffic control signal shall be based on having a continuous view of at least two signal faces for the distance specified.

Support

Permanent obstructions causing the limited visibility might include roadway alignment or structures. Intermittent obstructions might include foliage or parked vehicles.

Guidance

Where intermittent obstructions occur, engineering judgment should determine the treatment to be implemented.

Option

An Advance Traffic Control sign may be used for additional emphasis of the primary traffic control device, even when the visibility distance to the device is satisfactory.
An advance street name plaque may be installed above or below an Advance Traffic Control sign.
A warning beacon may be used with an Advance Traffic Control sign.

Source: 2009 MUTCD

When to Use 36″ and 48″ Temporary Warning Signs

According to the MUTCD:

Type of Roadway	Sign Size
Conventional Road	36 × 36″
Freeway or Expressway	48 × 48″

Transportation engineers may find this answer acceptable since they have a deeper understanding of the MUTCD than most, but not everyone has this knowledge. Luckily, definitions of these terms are provided to help make some sense of what they are trying to convey. Here’s how the MUTCD defines each of those types of roadways:

"Conventional Road" is a "street or highway other than a low-volume road, expressway, or freeway."
"Low-Volume Road" is a facility lying outside of developed areas of cities, towns, and communities, which serves fewer than 400 vehicles per day on average. A low-volume road shall not be a freeway, an expressway, an interchange ramp, a freeway service road, a road on a designated State highway system, or a residential street in a neighborhood.
"Expressway" is a divided highway with partial control of access.
"Freeway" is a divided highway with full control of access.

Still confused? It's not just you. Generally speaking, if the road is a divided highway with a concrete barrier or median, a 48 × 48″ sign will be required. A 36 × 36″ sign can be used on all other types of roadways.

Details

Roll-Up Signs

Roll-up signs material grades

Fluorescent Non-Reflective Solid Vinyl signs are recommended for day time use only, this material is not MUTCD compliant when used at night.
Fluorescent Super Bright Reflective Vinyl signs are MUTCD compliant when used day or night.

Roll-Up Sign Bracket Compatibility

Compatible with Latch Brackets.
Compatible with Universal Brackets.
Compatible with all Roll-up Brackets.
View and order sign stands with roll-up bracket options.

36" Roll-Up Sign Features

Unit Weight, without flags: 4 lb
Unit Weight, with flags: 5 lb
Storage Size: 4" x 4" x 50"

48" Roll-Up Sign Features

Unit Weight, without flags: 6.45 lb
Unit Weight, with flags: 7.25 lb
Storage Size: 5" x 5" x 67"

Roll-Up Sign Plastic Corner Pockets

At 3/4" deep, the Delta Rib Pocket is designed to be easier to deploy than conventional pockets. Made of tough polycarbonate, it features increased strength and the smallest storage diameter in the industry.

Featuring a full depth design, rectangular pockets are typically used at the top and bottom of the sign. Made of tough polycarbonate, they will fit all pocket style sign holders.

MUTCD Compliance

2009 Edition Part 6 Figure 6F-2. Methods of Mounting Signs Other Than on Posts

The fourth example shows an orange diamond-shaped sign with a black border and letters with the words "UTILITY WORK AHEAD" in three lines mounted on a vertical pole that is mounted on four horizontal supports. The distance from the bottom of the sign to the bottom of the supports is labeled as "1 ft MIN. above the traveled way." At the top of the sign, three orange flags are shown mounted equidistant apart from each other on short staffs that extend out from the top of the vertical pole at 45-degree angles.
